Key Specifications / Features
- Model no.: CGS-20250312-CGS-01
- Hits: 0
- Categories: Containerized Generator Set
Detail Information
Product Name: 1200kW 1500kVA Containerized Generator Set, Soundproof
Fuel Type: Diesel
Engine Model: Yuchai YC12VC2070-D31
Cylinder Number: 12 Cylinders Inline
Phase/Wire: 3 Phase 4 Wires
Rated Power: 1200kW, 1500kVA
Standby Power: 1350kW, 1650kVA
Rated Voltage: 400/230V
Rate Current: 2176 A
Rated Speed/Frequency: 1500 RPM/50Hz
Battery Rating Capacity: 4 * 200AH 12V
Dimension(L×W×H): 5446*1650*2218 mm
Weight: 13112 kg
Engine Data
|
Engine Brand |
Yuchai |
|
Engine Model |
YC12VC2070-D31 |
|
Prime Power |
1380kW, 1725kVA |
|
Standby Power |
1520kW, 1900kVA |
|
Number of Cylinders & Configuration |
12 cylinders in line |
|
Bore x Stroke |
200 mm *210 mm |
|
Displacement |
79.17 L |
|
Compression Ratio |
13.5:1 |
|
Governor Type |
Electric start |
|
Rated RPM |
1500 |
Generator Set Systems
|
Exhaust System |
Exhaust Gas Flow |
33 m³/min |
|
Max. Exhaust Gas Temperature |
550 °C |
|
|
Max. Exhaust Back Pressure |
10 kPa |
|
|
Air Intake System |
Aspiration Type |
Turbocharged intercooler |
|
Max. Intake Depression |
12 kPa |
|
|
Combustion Air Volume |
33 m³/min |
|
|
Fuel System |
Rating Fuel Consumption |
50.4 L/h |
|
75% Full Fuel Consumption |
37.4 L/h |
|
|
Lubrication System |
Total Oil Capacity |
21 L |
|
Max. Permissible Oil Temperature |
97 °C |
|
|
Oil Pressure at Rated RPM |
345-413 kPa |
|
|
Cooling System |
Total Coolant Capacity |
10 L |
|
Max. Temperature of Coolant |
550 °C |
|
|
Fan Cooling Air Flow |
125 m³/min |
Alternator Data
|
Rating Voltage |
400/230 V |
|
Rating Capacity |
1200kW, 1500kVA |
|
Efficiency |
87.5% |
|
Power Factor |
0.8 |
|
Exciting Type |
Brushless self-exciter, AVR |
|
Voltage Regulation |
±0.5% |
|
Number of Phases |
3 phase, 4 wire |
|
Enclosure Class |
IP23 |
|
Class of Insulation |
H |
