Key Specifications / Features
- Model no.: CGS-20250312-TMGS-01
- Hits: 0
- Categories: Trailer Mounted Generator Set
Detail Information
Product Name: Trailer Mounted Diesel Generator Set, Mobile Generator Set
Fuel: Diesel
Engine: Deutz D226B-3D
Alternator: Stamford PI142F
Prime Power: 24kW, 30kVA
Standby Power: 26kW, 33kVA
Power Factor: 0.8
Frequency: 50 Hz
Output Voltage: 400/230 V
Rated Current: 39A
Oil Consumption: 0.07 L/H
Dimension (Soundproof): 2300 * 900 * 1250 mm
Weight (Soundproof): 1090 kg
Engine Specifications
|
Engine Brand |
Deutz |
|
Engine Model |
D226B-3D |
|
Number of Cylinders |
3 Cylinder in-line |
|
Bore |
105 mm |
|
Stroke |
120 mm |
|
Displacement |
3.12 L |
|
Cooling Fan Air Flow |
155 m³/min |
|
Compress Air Flow |
2.83 m³/min |
|
Exhaust Gas Flow |
6 m³/min |
|
Exhaust Gas Temperature |
470 °C |
|
Lubrication Oil Capacity |
7.75 L |
|
Cooling Water Capacity |
17 L |
|
Starting Voltage |
24 V |
|
Engine Max. Output Power |
33kW |
Alternator Specifications
|
Brand |
Stamford |
|
Model |
PI142F |
|
Rated Output |
32kVA |
|
Frequency |
50 Hz |
|
Altitude |
≤1000 m |
|
Insulation |
Class H |
|
Protection Grade |
IP23 |
|
Alternator Options |
Leroy Somer, Marathon, Mecc Alte, Chinese brand Brushless |
Control Panel Specifications
|
Controller Brand |
Deepsea |
|
Controller Model |
DSE7320 |
|
Functions |
Automatic genset start/stop |
|
Automatic battery charger |
|
|
Emergency stop |
|
|
AMF (Automatic Mains Fault) |
|
|
Remote control |
|
|
Micro-processor based design |
|
|
LED alarm indication and sound alarm |
|
|
Display Features |
Generator voltage (Uab, Ubc, Uca) |
|
Generator current (Ua, Ub, Uc) |
|
|
Generator temperature (°C/°F) |
|
|
Generator frequency (Hz) |
|
|
Generator power (kW, kVA, kWh, kVAr, kVArh, kVAh) |
|
|
Generator start count (Max 999999) |
|
|
Generator pressure (kPa/Psi/Bar) |
|
|
Charging voltage (V) |
|
|
Battery voltage (V DC) |
Protection and Alarms
|
Protection |
Alarm Features |
|
Over/Under Speed Alarm and Shutdown |
High Engine Temperature Alarm and Shutdown |
|
Start/Stop Failure Alarm |
Over Load Alarm and Shutdown |
|
Over Current Alarm and Shutdown |
Low and High Battery Voltage Alarm |
|
Under/Over Generator Voltage Alarm |
Loss of Speed Signal Alarm and Shutdown |
|
Low Oil Pressure Alarm and Shutdown |
Charge Fail Alarm |
